Move 30N
Move 30 N is a member of the car parking lift family that operates with a two column system with the columns placed on opposite sides along the longer sides of platform. This model requires walls on either side to attach to but does not impose the same loads as the Move 30 L. It can serve up to16 metres thereby covering most of the markets needs. It has the double value of a car parking lift and a goods lift.
Description
Move 30 N also
has a torsion bar system that prevents the vehicle weight from putting the platform out of balance. Moreover, it ensures greater safety while the platform is moving. The important fact is that the torsion bar slides on a rack which is a self-contained element and thus does not affect the column structure.
The mechanical system
locking the platform to the floor is of vital importance. Operated by a hydraulic piston, it ensures perfect platform safety, connecting the shoulder to the piston and preventing untimely movement while the vehicle is being parked on the platform itself.
Moreover, when the connection is made, the entire hydraulic system can be set at rest, safeguarding it and extending its lifespan.
Moreover, when the connection is made, the entire hydraulic system can be set at rest, safeguarding it and extending its lifespan.
Move 30 N
has a piston (manufactured by O.ME.R. S.p.A.) with chain (ratio 1:2) so the travel vs. the length of the shaft can be doubled.
The top of the piston holds a pulley over which a chain slides; it is protected by a metal plate which prevents the chain from leaving its housing.
The top of the piston holds a pulley over which a chain slides; it is protected by a metal plate which prevents the chain from leaving its housing.
Move 30 N
has different limit switch systems. The stop limit switch stops the platform at the level indicated and ensures that it is safe to embark or disembark.
